Description：

Film: 160 micron PVC foam film;

Adhesive： Water-based permanent adhesive;

Liner：140gsm white PEK paper with one side PE & Silicon coating;

Width：1.37m， length roll: 50M

Packing: paper carton.  Core: 3inch.

Features：

1.Superior appearance with textured and embossed style;

2.Easy application to a wide variety of substrates ,especially on the glossy surface.

3.Excellent printability and handling;

4.Good dimensional stability after application;

Applications：

Indoor wall decoration & exhibition advertisement, etc.,

Printing Method:  Solvent ink, Eco-solvent ink and UV.

Technical Data：

Testing condition: Indoor temperature 23±2℃;Relative humidity 50±5%;Use aluminum, glass, steel plate as the base material for testing

Storage Condition：

All products always need to be stored in the original packing and with the original protection materials, preferably stored hermetically, no more than 6 layers if stored horizontally. Do not expose in direct sunlight or heat sources. Shelf life will be one year with temperature of 25°C ± 5°C and relative humidity of 50 ±15%.

Production and Application Environment：

Production environment: temperature of 25 ± 5 °C, relative humidity of 50%±10%, clean dust-free environment without suspended matter; Please move the materials to the printing environment 24 hours before printing ,printing test before use and remain enough edge margins when printing..

Application environment: temperature of 20±10℃, relative humidity of 50±10%; Pasting on flat, smooth and clean surface without floating dust and shedding; It is necessary to take more than 2 hours for maintenance before laminating

Warranty Condition:
1. One year shelf life: stored in suitable conditions, preferably use within six months.
2. One year prosecution period: from the product manufacture date, no-acceptance for overdue product.

Important Remark:

The information mentioned in this product data sheet is based upon tests that were executed by NAR, and that we consider to be reliable. Environment humidity more than 70% in different district will decrease the printing result.

This SAV product is with permanent glue and have the possibility of residual gum with different substrate and pasting period. Advise to use the same batch product to joint.
