Transparent self adhesive vinyl

Product advantages and uses:

Through the coverage of self adhesive vinyl, all kinds of vehicles, aircrafts, boats and other means of transportation are transformed into moment and personalized display media, which also has good performance in various types of board, glass curtain wall and other indoor and outdoor print advertising fields.

Art.NO.: RH-6203


Transparent Self Adhesive Vinyl

Description:

Film:       80 micron; transparent glossy PVC film

Adhesive:  Clear permanent adhesive;

Liner:     120gsm white paper with one side PE & Silicon coating

Width:    1.06/1.27/1.37/1.52m

Features:

1.  Spray painting on one side, paste on glass, acrylic transparent objects, with double-side visual effect.

2.  Excellent printability and dimensional stability.

Applications:

Applicable to Vehicle Wrapping Media, Glass curtain, indoor and outdoor advertising.

Suitable for various of solvent ink, Eco-solvent ink and UV ink.

Technical Data:

Testing condition: Indoor temperature 23±2°C;Relative humidity 50±5%;Use aluminum, glass, steel plate as the base material for testing.

Test Items

Units

Test method

Average value

Thickness PVC

Weight-Liner

Weight -finished product

Initial Adhesion

24h, 180°peel

Dimensional stability MD

Dimensional stability CD

Tensile strength MD

Tensile strength CD

Construction Temperature

Applicable Temperature

Micron

g/m²

g/m²

N/25mm

N/25mm

mm

mm

N/25 mm

N/25 mm

°C

°C

GB/T6672-2001

GB4669-1995

GB4669-1995

FTM 9

FTM 1

FTM 14

FTM 14

GB/T1040.1-2006

GB/T1040.1-2006



80±10

120±10

245±20

≥7

≥9

≤1.5

≤1.0

≥40

≥35

20±10°C

-20 ~ +70

All technical data is subject to change without prior notice.

Code ART NOPRODUCT NAMETECHNICAL DATAAVAILABLE SIZE
weight and thickness suitable for printer WIDTH(M)LENGTH(M)
1RH-6203Gtransparent  self adhesive vinylglossy /pvc 80um, release paper:120gsmSOLVENT/ECO SOLVENT /UV0.914/1.07/1.27/1.37/1.5250
glossy /pvc 100um, release paper:120gsmECO SOLVENT /SOLVENT/UV0.914/1.07/1.27/1.37/1.5250
※ Maximum 5% tolerance for film and liner.
※ Available in both glossy and matte surface.
※ Other size or thickness can be produced as requested or negotiable.

 Storage Condition:

All products always need to be stored in the original packing and with the original protection materials, preferably stored hermetically, no more than 6 layers if stored horizontally. Do not expose in direct sunlight or heat sources. Shelf life will be one year with temperature of 25°C±5°C and relative humidity of 50±15%.

  Production and Application Environment:

Production environment: temperature of 25±5°C, relative humidity of 50%±10%, clean dust-free environment without suspended matter; Please move the materials to the printing environment 24 hours before printing. Test prior to use and remain enough edge margins when printing.

Application environment: temperature of 20±10°C, relative humidity of 50±10%; Pasting on flat, smooth and clean surface without floating dust and shedding; It is necessary to take more than 2 hours for maintenance before laminating.

Warranty Condition:

1.  One year shelf life: stored in suitable conditions, preferably use within six months.

2.  One year prosecution period: from the product manufacture date, no-acceptance for overdue product.
