Colour car wrap film

Product advantages and uses:

Art.NO.: RH-9000


Origin country : China

Product Description:

colour Vinyl wrap films are multi-layered, high performance PVC film designed especially for full vehicle wrapping. It is available in many colours, such as Glossy series, Matt series, Pearl Metal Series, Crystal series etc.

The special adhesive enables adhesion onto lacquered surfaces, as well as onto uneven and corrugated surfaces. The applied material is easy to remove with the appropriated equipment.

----------------------------------------------------------------------------------------------------------------------------------------------

Protective Liner: PET

Face:PVC Films+colour liner 120-150um.

Adhesive:Customized special glue

Release Liner: double-sided lamination embossing PET 75um

Width:1.52m

Outdoor Durability:  2years

 Features:

●Unique perfect Finish solid colours

● Unique adhesive technology.

● Good conformability to irregular substrates

● Outstanding durability and outdoor performance

● Good UV, temperature, humidity, and salt-spray resistance

●Airrelease technology enables bubble free flow out during installation

Appearance performance:

Product

Colourful Vinyl Wrap Film

Application

Trucks, cars& Vans, Trailers, Architectural Signage, Buses, Emergency Vehicles, tanks etc

Model

---

Testing method

Bubble

invisible

Visually

Dirty spots

invisible

Visually

Crystal dot

Uneven dot

0.01-0.06mm

Uncountable

Visually

0.07-0.29mm

<20pcs

≥0.3mm

Allow 1pc

Glue line

invisible

Visually

 Physical Properties:

Product

Colourful Vinyl Wrap Film

Model

-----

Testing method

Application method

Dry


Gloss(60°)

≥90(%)

GB 8807

Weight (finished product)

310~370(g/m2)

GB/T 4669

Weight (Adhesive)

40~60(g/m2)

Thickness(finished product)

260~340(um

GB/T 7125

Elongation at break %

200~300(%)

GB/T 1040.1

Dimensional stability(MD)

≤0.5(mm)

FINAT TM 14

Dimensional stability(TD)

≤0.4(mm)

Release

≤0.30(N/25mm)

GB/T 2792

initial tack

≥10(N/25mm)

FTM 9

24h,180° Peel force

≥8(N/25mm)

GB/T 2792

Resistance to solvents &chemicals

The adhesive is resistant to most chemicals(mild acids, alcohol, oils,salt solutions etc

Packing Features:

Product

Colourful Vinyl Wrap Film

Model
G70DH1521

3inch carton inner core tube/double-sided tape

PE Plastic carton inner/Packing Carton

 (White Cover & Black Cover)

Wooden pallet/packing bag/stretch film

 Packing Specifications

Roll Length

17~18 (m)

Roll Width

1.515~1.525 (m)

Packing method

Carton (size:17x17x159mm G.W.12.7kgs) & Pallet

----------------------------------------------------------------------------------------------------------------------------------------------

Storage:

Shelf life:2 years from the date of manufacture( stored at the following conditions:)

All products should be stored in the original packaging with original protective materials.

It is recommended to keep them sealed and placed horizontally.

The stacking height should not exceed 6 layers, and avoid direct sunlight and direct contact with heat sources.

The storage temperature is 25±5℃, and the relative humidity is 50±15%.
